New Arrivals SMD Down Light

Model Code: ILL-DL01806

Power: 18W
Input: AC220-240V, 50~60Hz
Dimension: Ф125*75 mm
Cutout: Ø115 mm
Lumen Flux: 1260 lm
CRI: >80.
Beam Angle: 110 deg.
LED: SMD
Power Supply: Eaglerise (Lifud, Philips and Tridonic optional).
Color Temperture: 2700K, 3000K, 4000K, 5000K, 5700K, 6500K
IP Rate: IP20

Categories:LED Down Light

Add To Basket Get A Quote

Product Description

Product Features:

1. Good quality die-cast aluminum make sure excellent heat dissipation.
2. 30° cut-off angle, good visual comfort with high luminous efficiency.
4. Accent lighting in an appearance of general lighting fixture.
5. Mellow and even light output filtered by a special optical diffuser.

Material: Aluminum.

Application: Hotel, Shopping Mall, Store and Office.

Full Specifications:

No.

Model Code

Power

(W)

Dimension

(mm)

Cutout

(mm)

Beam Angle

1

ILL-DL00706

7

Ф85*50

Ф75

110°

2

ILL-DL01206

12

Ф105*63

Ф95

110°

3

ILL-DL01806

18

Ф125*75

Ф115

110°

No.	Model Code	Power (W)	Dimension (mm)	Cutout (mm)	Beam Angle
1	ILL-DL00706	7	Ф85*50	Ф75	110°
2	ILL-DL01206	12	Ф105*63	Ф95	110°
3	ILL-DL01806	18	Ф125*75	Ф115	110°
